Aiphone Vandal-Resistant Video Intercom Kit JPS-4AEDV

$ Call for Pricing

  • 7″ Touchscreen Video Intercom
  • Vandal-resistant door station
  • Includes JP-MED Master Station
  • Connect up to 8 inside stations (Master + 7 JP-4HD)
  • Hands-Free auto-voice actuation
Category:

Description

Aiphone JPS-4AEDV Video Intercom Kit

Kit includes one JP-4MED video intercom answering station, one JP-DV surface-mounted, vandal-resistant video door station, and one PS-2420UL 24v UL listed DC power supply.

Type of communication

  • Hands-free auto-voice actuation, Handset Simultaneous Communication

Camera

  • Type: 1/4″ CMOS
  • Viewing Angle: Wide (approx. 100° x 170°) with Digital Pan, Tilt, and Zoom

Wire Type

  • Door Station to Master Station: 2 cond., mid cap, solid, non shielded – use Aiphone #871802
  • Power Supply to Master Station: 2 cond., mid cap,solid, non shielded – use Aiphone #871802

Wire Distance

  • Door Station to Master Station: 165′ (22AWG) 330′ (18AWG)
  • Power Supply to Master Station: 16′(22AWG) 33′(18AWG)



JP-4HD 7″ Video Sub Station with Touchscreen LCD

The JP-4HD is a sub-station for the JP Series. Up to 7 of these sub-stations attaches to the JP-4MED Master Station and will receive calls from JP door stations attached to the JP-4MED. If enabled, these stations can also communicate with the JP-4MED and other JP-4HDs attached to the system for internal communication.

Features

  • 7″ Touchscreen LCD
  • Hands-free (VOX) or handset (duplex) communication
  • Selective door release controls
  • Room-to-room calling
  • Door Station Monitoring
  • Hearing Aid T-Mode Compatibility
  • Digital Pan, Tilt, and Zoom
  • Brightness Control
  • Connects to JP-4MED or JP-8Z with a single Cat-5e cable
  • Daisy-Chain up to 7 Video Sub-Stations, or Home-Run them with JP-8Z Distribution Adapter (may require additional power supplies, depending on number of Video Sub Stations)

Power consumption

  • 200mA (max.)

Video Monitor

  • 7″ TFT color touchscreen LCD

Type of communication

  • Handset: Simultaneous communication
    Hands-free: Auto-voice actuation

Mounting

  • Surface wall mount or desk mount using MCW-S/A (sold separately)

Wire Type

  • Between Master/JP-8Z to Sub Master: Cat-5e or Cat-6

Wire Distance

  • JP-8Z to Sub Master: 165′
    Master to Sub Master with power supply: 650′
    Master to Sub Master without power supply: 98′

Temperature Rating

  • 32-104°F (0-40°C)

Dimensions

  • 5-11/16″ H x 10-1/16″ W x 1-7/8″ D
